ALICON
B230
- Weight
- 1,777kg
- Suitable Excavator
- 18~25ton
Specifications
Metric
US/Imperial
Description | Unit | - | ||
---|---|---|---|---|
Control Valve Type | - | Outer control valve installed with accumulator | - | Outer control valve installed with accumulator |
Suitable Excavator | ton | 18~25 | lb | 39,683~55,116 |
Weight [Top box type] | kg | 1,777 | lb | 3,918 |
Overall Length [Top box type] | mm | 2,764 | in | 108.8 |
Weight [Side type] | kg | 1,663 | lb | 3,666 |
Overall Length [Side type] | mm | 2,348 | in | 92.4 |
Weight [Split type] | kg | 1,891 | lb | 4,169 |
Overall Length [Split type] | mm | 2,764 | in | 108.8 |
Chisel Out Diameter | mm | 140 | in | 5.5 |
Working Length of chisel [Top box type] | mm | 1,250 | in | 49.2 |
Setting Pressure | kgf/cm² | 210 | psi | 2,987 |
Working Pressure | kgf/cm² | 130~180 | psi | 1,849~2,560 |
Oil Flow | LPM | 130~170 | GPM | 34.3~44.9 |
Blow Rate [Standard speed] | BPM | 250~400 | BPM | 250~400 |
Blow Rate [High speed] | BPM | 350~500 | BPM | 350~500 |
Back Head N2 Gas Pressure | kgf/cm² | 8~11 | psi | 114~156 |
※ The specifications are subject to change without prior notice for quality improvement.
※ Weight includes mounting bracket to attach to excavator and may vary depending on mounting bracket configuration.
Application
Standard [●] Option [○]
Description | - |
---|---|
Under water works | ○ |
Auto greasing system hole | ● |
TPC (Total Power Control) system selector type | ● |
ABF (Anti Blank Firing) system | ● |
Auto greasing unit | ○ |
Central grease supply unit | ○ |
BPM adjuster | ● |
Internal relief valve | ○ |
TPC (Total Power Control) system remote control type | ○ |
Low noise housing bracket | ○ |
