DMC FIXED PULVERIZER
DMC210
- Weight
- 1,926kg
- Suitable Excavator
- 20~28ton
Specifications
Metric
US/Imperial
Description | Unit | - | ||
---|---|---|---|---|
Weight | kg | 1,926 | lb | 4,246 |
Overall Length | mm | 2,222 | in | 87.5 |
Jaw Opening | mm | 784 | in | 30.9 |
Jaw Depth | mm | 816.5 | in | 32.1 |
Blade Length | mm | 180 | in | 7.1 |
Upper Jaw Width | mm | 426 | in | 16.8 |
Lower Jaw Width | mm | 600 | in | 23.6 |
Crushing Force(Mid) | ton | 132 | sh.tn. | 148 |
Crushing Force(Tip) | ton | 64 | sh.tn. | 72 |
Min. Cycle Time (Open/Close) | sec | 1.8 / 1.6 | sec | 1.8 / 1.6 |
Operating Pressure | kgf/cm² | 350 | psi | 4,978 |
Oil Flow Rate | LPM | 200~250 | GPM | 52.8~66.0 |
Excavator Class | ton | 20~28 | lb | 44,092~61,729 |
※ The specifications are subject to change without prior notice for quality improvement.
※ Weight includes mounting bracket to attach to excavator and may vary depending on mounting bracket configuration.
